RTS Intercoms proudly presents the new NOMAD system, a long-awaited innovation in the field of digital wireless intercom systems. The system is based on an access point that connects via Omnio to intercom matrices such as OMI, Atom or Omnio Odin.
ACCESS POINT FEATURES
The access point features local power supply, uninterrupted redundant network connection (fiber or copper), and GPIO. Thanks to its robust structure, it has an IP65 rating making it suitable for outdoor use. Initially developed in a black version, it was subsequently created in white color for outdoor use, as the black version would overheat in direct sunlight.
BELT PACK CONNECTIVITY
The belt packs connect to the access point via the new Dect chip. Each access point can manage 10 belt packs, and the system can be expanded to a total of 200 belt packs. The belt pack is equipped with 4 buttons with volume control, configuration menu and call buttons, but offers access to 16 channels distributed across multiple pages. This allows users to listen to different sources such as cameras, program sound, other field operators or the hybrid telephone.
BELT PACK COMPONENTS
The belt pack includes:
- Built-in speaker and microphone
- USB-C and mini jack connection
- Field-interchangeable connector (5 or 4-pin female, or 4-pin male)
- Activatable flashlight
- Call function
- Battery release clip
POWER AND ACCESSORIES
The battery can be recharged separately or together with the belt pack in the charger. Accessories such as camera tripod mounts and belt clips are available.
TECHNOLOGY FEATURES
The system uses high-quality codecs and Dect technology for connection to the access point. It also offers Bluetooth connectivity for third-party devices such as mobile phones or headsets, and BLE (Bluetooth Low Energy) which allows belt pack programming to the access point even from a distance, for example from the studio floor while the access point is mounted 7 meters high.
SPECIAL FUNCTIONS
A particularly useful feature is “Find my belt pack” which allows rental companies to easily locate belt packs at the end of a show.
DESIGN HIGHLIGHTS
The Nomad system is characterized by its IP65 housing for outdoor use and a vibration mode that alerts the user of incoming calls when the belt pack is positioned on the neck with headphones.
IL NUOVO SISTEMA RIVOLUZIONARIO NOMAD DI RTS
RTS Intercoms presenta con entusiasmo il nuovo sistema Nomad, un’attesa innovazione nel campo dei sistemi intercom wireless digitali. Il sistema è basato su un access point che si connette tramite Omnio alle matrici intercom come OMI, Atom o Omnio Odin.
L’access point è dotato di alimentazione locale, connessione di rete ridondante (in fibra o rame) senza interruzioni, e GPIO. Grazie alla sua struttura robusta, ha una classificazione IP65 che lo rende adatto all’uso esterno. Inizialmente sviluppato in versione nera, è stato successivamente creato anche in colore bianco per l’uso all’aperto, poiché la versione nera si surriscaldava alla luce diretta del sole.
I belt pack si collegano all’access point tramite il nuovo chip Dect. Ogni access point può gestire 10 belt pack, e il sistema può essere espanso fino a 200 belt pack complessivi. Il belt pack è dotato di 4 tasti con controllo del volume, menu di configurazione e pulsanti di chiamata, ma offre accesso a 16 canali distribuiti su più pagine. Questo permette di ascoltare diverse fonti come telecamere, suono di programma, altri operatori sul campo o il telefono ibrido.
Il belt pack include:
- Altoparlante e microfono integrati
- Connessione USB-C e mini jack
- Connettore intercambiabile sul campo (femmina a 5 o 4 pin, o maschio a 4 pin)
- Torcia attivabile
- Funzione di chiamata
- Clip per il rilascio della batteria
La batteria può essere ricaricata separatamente o insieme al belt pack nel caricatore. Sono disponibili accessori come supporti per treppiedi fotografici e clip da cintura.
Il sistema utilizza codec di alta qualità e la tecnologia Dect per la connessione all’access point. Offre anche connettività Bluetooth per dispositivi di terze parti come telefoni cellulari o cuffie, e BLE (Bluetooth Low Energy) che consente di programmare il belt pack all’access point anche a distanza, ad esempio dal pavimento dello studio mentre l’access point è montato a 7 metri d’altezza.
Una funzionalità particolarmente utile è “Find my belt pack” che permette alle società di noleggio di localizzare facilmente i belt pack alla fine di uno spettacolo.
Il sistema Nomad è caratterizzato dal suo alloggiamento IP65 per uso esterno e da una modalità di vibrazione che avvisa l’utente delle chiamate in arrivo quando il belt pack è posizionato sul collo con le cuffie.
